High Tensile Fasteners

Discover M10 High Tensile Studs at HT Nut Bolt in Indonesia - Your Semantics SEO Expert

High Tensile Fasteners Manufacturer in Indonesia Piping Material excels as a leading manufacturer in Indonesia, specializing in high tensile fasteners essential for high-stress applications. Their wide range includes various types, grades, and sizes to secure components under extreme pressure with superior strength.

HT Nut Bolt

M10 High Tensile Studs

Check Updated Price List of M8 High Tensile Bolt Strength, High Tensile Bolt Material, High Tensile Steel Threaded Rod

High Tensile Fasteners Manufacturer in Indonesia

Offering various grades like 10.9, 8.8, DIN 933, and 12.9, along with standards like IS1364, IS1363, DIN EN ISO 4014, this manufacturer produces fasteners ranging from 20mm to 100mm. The HT Nut Bolt types cater to diverse applications, connected securely via threads.

The high tensile fasteners manufacturer in Indonesia produces a variety of bolts and nuts with male and female threads. The M10 High Tensile Studs are 10mm in diameter, with threads on both ends, while the M8 bolts are around 8mm. These bolts are made of chromium nickel and nickel copper alloys for high tensile strength. Contact us for pricing and more product information.

Standard Specification Of HT Nut Bolt

Grades	Grade 10.9, Grade 8.8, DIN 933 Grade 12.9
Standard	IS 1364 / IS 1363 & DIN EN ISO 4014 & 4017 DIN 931 / 933
Size	Dia M 20 to 100 mm Inch 3/4" to 3.1/2"
finish	Zinc plated / Plain / Hot dip galvanised

Material properties of M10 High Tensile Studs

Nominal Size Range (mm)
Class 8.8: Medium carbon steel, quenched and tempered
Class 10.9: Alloy steel, quenched and tempered
Class 12.9: Alloy steel, quenched and tempered

Different High Tensile Bolt Types

High Tensile 210mm stainless steel u-bolt

HT 210mm stainless steel u-bolt

High Tensile Fastener nut and bolt, din931 Hex Bolts and Nuts

High Tensile Fasteners nut and bolt, din931 Hex Bolts and Nuts

T Bolts High Tensile Strength Fastener M8 X 25

T Bolts HT Strength Fasteners M8 X 25

T hammer head Bolts High Tensile Strength Fastener M8 X 25

T hammer head Bolts High Tensile Strength Fasteners M8 X 25

4F3653 for Excavators high Tensile Fastener 40Cr 5/8 inch Plow Bolts & Nuts

4F3653 for Excavators high Tensile Fasteners 40Cr 5/8" Plow Bolts & Nuts

Nuts Bolts Fasteners high tensile hinge bolt

high tensile hex bolts shoulder nut m32 fasteners

HT hex bolts shoulder nut m32 fasteners

High tensile M2 to M12 clamp u bolt with nut screw

HT M2 to M12 clamp u bolt with nut screw

High Tensile Steel Sleeve Anchor Fastener Bolt

High Tensile Steel Sleeve Anchor Fasteners Bolt

High tensile J hook anchor bolt

high tensile U- bolts

HT Fasteners nut and bolt

Supplier of High Tensile Hex Bolt, Ht Set Screw available in a wide range of grades and shapes, M16*50 High Tensile Washer Dimensions

Dimension of Ht Set Screw

Bolts Size	A O.D.	B I.D.	C Thickness
Bolts Size	A O.D.	B I.D.	Min	Max
1/4"	5/8	9/32	0.051	0.080
5/16"	11/16	11/32	0.051	0.080
3/8"	13/16	13/32	0.051	0.080
7/16"	59/64	15/32	0.051	0.080
1/2"	1-1/16	17.32	0.097	0.177
5/8"	1-5/16	11/16	0.122	0.177
3/4"	1-15/32	13/16	0.122	0.177
7/8"	1-3/4	15/16	0.136	0.177
1"	2	1-1/8	0.136	0.177
1-1/8"	2-1/4	1-1/4	0.136	0.177
1-1/4"	2-1/2	1-3/8	0.136	0.177
1-3/8"	2-3/4	1-1/2	0.136	0.177
1-1/2"	3	1-5/8	0.136	0.177
1-3/4"	3-3/8	1-7/8	0.178	0.28
2"	3-3/4	2-1/8	0.178	0.28
2-1/4"	4	2-3/8	0.24	0.34
2-1/2"	4-1/2	2-5/8	0.24	0.34
2-3/4"	5	2-7/8	0.24	0.34
3"	5-1/2	3-1/8	0.24	0.34
3-1/4"	6	3-3/8	0.24	0.34
3-1/2"	6-1/2	3-5/8	0.24	0.34
3-3/4"	7	3-7/8	0.24	0.34
4"	7-1/2	4-1/8	0.24	0.34

High Tensile Hex Head Bolts, Certified Materials M12 Customized ASTM F568 HT Countersuck Screw Weight Chart - M12 High Tensile Coach Bolts

Weight of M8 High Tensile Bolt

LENGTH in Milimeter
LENGTH in Milimeter	M 5	M 6	M 8	M 10	M 12	M 14	M 16	M 18	M 20	M 22
16	0.448	0.743	1.590	3.211
20	0.598	0.812	1.711	3.411	4.892
25	0.660	0.897	1.871	3.660	5.252	8.170
30	0.737	1.010	2.070	3.912	5.574	9.690	10.707		18.657
35	0.804	1.120	2.271	4.223	5.974	10.000	11.416	16.026	19.608
40	0.881	1.230	2.470	4.533	6.410	10.288	12.107	16.667	20.747
45	0.958	1.340	2.671	4.840	6.859	10.504	12.821	17.241	21.739
50	1.030	1.450	2.870	5.155	7.299	11.261	13.624	17.857	22.727	28.409
55		1.560	3.071	5.464	7.740	11.628	14.409	18.868	23.810	30.120
60		1.670	3.270	5.774	8.183	12.255	15.244	20.000	25.126	32.051
65		1.781	3.472	6.083	8.621	12.626	16.026	21.008	26.455	34.014
70		1.890	3.671	6.394	9.058	12.987	16.835	22.124	27.778	35.461
75		2.000	3.873	6.702	9.506	13.228	17.606	23.256	29.070	39.063
80		2.111	4.072	7.013	10.000	13.889	18.248	24.510	30.303	40.000
90			4.472	7.634	10.917	14.925	19.841	26.042	33.113	41.667
100			4.873	8.251	11.820	16.340	21.459	27.778	35.714	46.296
110				8.881	12.723	17.730	23.041	31.250	38.168	47.170
120				9.506	13.624	18.797	24.631	32.895	40.984	50.000
130				10.101	14.535	20.000	26.316	34.722	43.478	52.632
140				10.707	15.432	20.833	27.933	35.461	46.296	55.556
150				11.312	16.340	22.222	29.412	37.594	48.544	58.824
160				11.905	17.241	24.272	31.056	40.984	50.505	61.728
170				12.500	18.116		32.680		53.191	64.935
180				13.123	19.011	26.882	34.247		55.556	67.568
190				13.736	19.920		35.971		58.140	70.423
200				14.327	20.833	29.586	37.594	49.020	60.976	73.529
220				15.528	22.624		40.650		65.789	79.365
240				16.722	24.510		43.860		71.429	84.746
250				17.301	25.381		45.455		74.627	87.719
260				17.921	26.316		47.170		76.923	90.909
280				19.157	28.090		50.505		81.967	98.039
300				20.325	29.940		53.763		87.719	104.167
320					31.646		56.818		92.593
340					33.557		60.241		98.039
360					35.211		63.291		104.167
380					37.037		66.667		108.696
400					39.063		69.444		113.636

Check HT Nut Bolt Size Chart from long established High Tensile Fasteners Manufacturers in Indonesia, Suppliers of F568 High Tensile Flat Washers

Sizes of High Tensile Steel Threaded Rod

High Tensile Fasteners Type	SIZE	GRADE	ASME	ISO	ASTM
ASTM F568 Socket Head Cap Fasteners	M1.6 to M64	12.9	B18.3.1 M	4762	A574M
Socket Low Head Cap Fasteners	M4 to M20	10.9
ASTM F568 Socket Head Shoulder Fasteners	M6 to M24	012.9	B18.3.3M
Countersunk Socket Head Fasteners	M3 to M20	012.9	B18.3.5M	10642	F835M
ASME SF568 Button Head Socket Fasteners	M3 to M12	012.9	B18.3.4M	7380	F835M
Flange Button Head Socket Fasteners	M3 to M10	012.9			F835M
HT Knurled Point Socket Set Fasteners	M3 to M20	45H	B18.3.6M	4029	F912M
Flat Point Socket Set Fasteners	M6 to M12	45H	B18.3.6M	4026	F912M
Dog Point Socket Set Fasteners	M3 to M20	45H	B18.3.6M	4028	F912M
Cone Point Socket Set Fasteners	M3 to M12	45H	B18.3.6M	4027	F912M
HT Plain Point Socket Set Fasteners	M3 to M20	45H	B18.3.6M	4029	F912M
Taper Pressure Plug	M8 to M22	-

High Tensile Fasteners Type	SIZE	PROPERTY CLASS	TENSILE STRENGTH	STANDARD
Hex Head Fasteners	M4 to M80	10.9	1040N / mm2 min	ISO 4017 (Full Thread) ISO 4014 (Half Thread)

High Tensile Nuts Type	SIZE	PROPERTY CLASS	STANDARD
M10 HT Hex Nut	M6 to M42	10	ISO 4032
HT Nylock Nut	M6 to M20 (Gr.8) M10 to M24 (Gr.10)	8 & `10	DIN 982
M8 HT Nylock Nut	M6 to M20 (Gr.8) M10 to M24 (Gr.10)	8 & 10	DIN 985
HT Hex Weld Nut	M6 to M12	8	DIN 929

High Tensile Washers Type	SIZE	HARDNESS	STANDARD
Square Section Spring Washer, High Tensile	3mm to 39mm	HV (430 to 530)	DIN 7980
Flat Section Spring Washer, High Tensile	3mm to 39mm	HV (430 to 530)	DIN 127 B
Hardened Washer, High Tensile	12mm to 30mm	HV (300 to 370)	IS 2016
Hardened Steel Washer, High Tensile	12mm to 56mm	Rockwell 26 to 45 (HDG) Rockwell 38 to 45 (Coated)	ASTM F436M

High Tensile Washer Price List

High Tensile Fasteners Price List	Price Per Pcs.
High Tensile Machine bolts price	USD $5.12
M10 HTHex head bolts price	USD $5.0
ASTM F568 HT Socket Head Cap Screw price	USD $3.60
HT Screws price	USD $4.70
M8 High Tensile Dowel Pins price	USD $2.20
